Kitchen Organization
Waste Bins

Salice Pull-Out
3
> Bottom or side mount
> Full extension
> Easy installation with 4 screws
> Waste bins feature integrated handles for easy removal
Kitchen Organization Door-mount
> Door mount brackets and clip handle included
> Weight capacity: 34 kg (75 lbs.)
> Material: Steel; Bin: Plastic

bracket patented
system features
3 way adjustability
for alignment of
the cabinet door:
height: (+/-2 mm),
side (+/-3 mm),
depth (+/-4 mm)

> Easy installation with 2 screws
> Suitable for standard and five piece doors
> Adjustment via #2 pozi driver

→ Single Bin Unit 12" → Double Bin Unit 15"

495 495
(19 1/2") (19 1/2") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

498 305 498 381
(19 5/8") (12") (19 5/8") (15")

> For 305 mm (12") opening > For 381 mm (15") opening
> W x D x H: 305 x 498 x 495 mm (12" x 19 5/8" x 19 1/2") > W x D x H: 381 x 498 x 495 mm (15" x 19 5/8" x 19 1/2")
> Capacity: 35 quarts > Capacity: 2 x 32 quarts (64 quarts)

Frame Bin Salice No. Item No. Frame Bin Salice No. Item No.
chrome silver QPAM12135C 503.00.520 chrome silver QPAM15228C 503.00.521
Supplied With Supplied With
Mounting screws Mounting screws
Mounting instructions Mounting instructions

FC 3.30 www.hafele.com/us
