Kitchen Organization
Waste Bins

Pull-Out Bottom Mount
3
> Quick installation with drilling template for floor and door
> Easy front adjustment in all directions
> For cabinets with overlay or inset doors
> With “V-Rail” reinforced side rails for more stability on full
Kitchen Organization > For use in face frame or frameless cabinets
height doors
> Optional “auto open” feature; a simple nudge gently opens
the unit
> Weight capacity: 45 kg (100 lbs.)
> Material: Steel, powder-coated; Bin: Plastic

Note
For replacement bins, see next page.

→ Frame with Single Waste Bin

319 (12 9/16") > Minimum height of opening: 36 qts. – 489 mm (19 1/4")
52 qts. – 610 mm (24")
> Minimum opening width: Face frame – 292 mm (11 1/2")
Frameless – 319 mm (12 9/16")
> Actual width of sliding unit: 283 mm (11 1/8")
> W × D × H: 292 × 568 × 254 mm (11 1/2" × 22 3/8" × 10")

568 (22 3/8") Frame Bin 36 qts. 52 qts. Bulk
chrome
502.56.222
502.56.230
white
502.56.220
gray
silver
502.56.930
502.56.922
502.56.920
champagne champagne 502.56.820 502.56.822 502.56.830
Note
Bulk pack supplied with 16 pcs.; bins are not included.
292 (11 1/2")
→ Frame with Double Waste Bins
397 (15 5/8") > Minimum height of opening: 36 qt. – 489 mm (19 1/4") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
52 qt. – 610 mm (24")
> Minimum width of opening: Face frame – 381 mm (15")
Frameless – 397 mm (15 5/8")
> Actual width of sliding unit: 372 mm (14 5/8")
> W × D × H: 355 × 568 × 254 mm (14" × 22 3/8" × 10")
568 (22 3/8") Frame Bin 2 x 36 qts. 2 x 52 qts. Bulk
502.56.250
502.56.240
502.56.242
white
chrome
silver
champagne gray 502.56.940 502.56.942 502.56.950
502.56.842
502.56.850
502.56.840
champagne
Note
Bulk pack supplied with 16 pcs.; bins are not included.
381 (15")
FC 3.28 www.hafele.com/us
