Home and Closet Organization
Standards and Brackets

KV

> Heavy duty
> Adjustable in 12 mm (1/2") increments
> BHMA Grade 1 compliant
> For surface or flush mounted applications
> Made in USA
> Weight capacity: up to 227 kg (500 lbs.)/pair*
4
*Note
Proper installation and mounting required. Tested to meet or exceed
ANSI/BHMA 156.9-2003 performance standards. Weight limits are
based on standards mounted on 406 mm (16") centers and are
Home and Closet Organization
intended for use as general guidelines only. No warranty, expressed or
implied, supplied by Häfele.
→ 255 Series Pilaster Standards → 256 Series Pilaster Supports for
255 Pilaster Standards

> Material: Steel

Finish KV Model No. Item No.
zinc 256 ZC 283.19.983

→ Nails for 255 Pilaster Standards

Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

> 23 gauge high strength steel
> Stamped numbers make installation easier
> Pre-drilled screw/nail holes
> Pre-punched staple holes > Material: Steel
> W x D: 16 x 5 mm (5/8" x 3/16")
> Material: Steel; Finish: zinc Finish KV Model No. Item No.
zinc 255-81N ZC 283.19.999
Length KV Model No. Item No. Supplied With
305 (12") 255 ZC 12 283.18.901 650 Nails
356 (18") 255 ZC 18 283.18.902
610 (24") 255 ZC 24 283.18.903
762 (30") 255 ZC 30 283.18.904
915 (36") 255 ZC 36 283.18.905
1219 (48") 255 ZC 48 283.18.907
1524 (60") 255 ZC 60 283.18.908
1829 (72") 255 ZC 72 283.18.909
2134 (84") 255 ZC 84 283.18.910
2438 (96") 255 ZC 96 283.18.911
Note
Mounting hardware is not included.

www.hafele.com/us FC 4.67
