Home and Closet Organization
Standards and Brackets

Shoptec

> Heavy duty
> Double slot design
> Adjustable in 25 mm (1") increments
> 16 gauge steel
> ANSI/BHMA 156.9-2003 Grade 2 Compliant
> Weight capacity: max. 425 lbs./pair
4

→ Double Standards

> W x D: 32 x 12 mm (1 1/4" x 1/2")
Flat Head > Material: Steel; Finish: zinc-plated
#10
Length Item No.
610 (24") 774.10.621
915 (36") 774.10.623
1219 (48") 774.10.625
1524 (60") 774.10.626 Home and Closet Organization
1829 (72") 774.10.628
2134 (84") 774.10.630
2438 (96") 774.10.632
Length
1.26
0.06 thick

Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

→ Brackets

> Double lug design provides secure support
> Material: Steel; Finish: zinc-plated

Length Item No.
203 (8") 774.11.622
254 (10") 774.11.624
305 (12") 774.11.626
356 (14") 774.11.629
406 (16") 774.11.630
457 (18") 774.11.631
508 (20") 774.11.633
559 (22") 774.11.634
Pan Head
#10 610 (24") 774.11.635
Length

4.44

Flat head screws pages 12.7–12.8, 12.10, 12.13
Pan head screws pages 12.9–12.10

www.hafele.com/us FC 4.61B
7/22
