Home and Closet Organization
Standards and Brackets

Coloma

> Brackets mount to slotted profile
> Gives shelves and drawers a floating appearance
> Material: Steel, powder-coated; Finish: silver

4

Home and Closet Organization

→ Cabinet Bracket Set → Concealed Cabinet Bracket Set

> Attaches to the back of the cabinet and is not visible
> Weight capacity: 50 kg (110 lbs.)
> Height: 120 mm (4 3/4")
> Specially designed to hold floating cabinets using 28.6 mm
(1 1/8") or 38 mm (1 1/2") thick material
> Weight capacity: 60 kg (132 lbs.) Item No.
793.00.448
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Depth Shelf thickness Silver Note
305 (12") 28.6 (1 1/8") 793.00.402 Use two sets to double the weight capacity.
Cannot be combined with the Cabinet Bracket Set.
356 (14") 28.6 (1 1/8") 793.00.414
457 (18") 28.6 (1 1/8") 793.00.426 → Glass Shelf Bracket Set
559 (22") 28.6 (1 1/8") 793.00.438
305 (12") 38 (1 1/2") 793.00.405
356 (14") 38 (1 1/2") 793.00.417
457 (18") 38 (1 1/2") 793.00.429
559 (22") 38 (1 1/2") 793.00.441
Note > For glass thickness from 4-10 mm (3/16"-3/8")
Use two sets to double the weight capacity. > Weight capacity: 45 kg (100 lbs.)
Cannot be combined with the Concealed Cabinet Bracket Set. > H x D: 81 x 127 mm (3 3/16" x 5")

→ Screw for Coloma Brackets
Item No.
793.00.450

Phillips Drive

> For attaching Coloma shelf and cabinet brackets
> Length: #6 x 30 mm (1 3/16")
> Material: Steel

Finish Item No.
zinc-plated 010.09.906

www.hafele.com/us FC 4.61
