Home and Closet Organization
Standards and Brackets

Coloma

→ Adjustable Leg

> For slotted profile 793.00.113
> Mounts to the bottom of the slotted profile
> Pin holds profile in place
> W x D: 41 x 41 mm (1 5/8" x 1 5/8") 4
> Height adjustable from: 22-37 mm (7/8"-1 7/16")
> Material: Steel

Finish Item No.
zinc-plated 793.00.003

> For slotted profile 793.00.114
> Material: Steel

Orientation Item No.
Right 793.00.129
Left 793.00.130 Home and Closet Organization

→ Panel Clip

> Attaches panels to slotted profiles
> Panels must be 19 mm (3/4") thick
> Clips allow back panel to be snapped into place by securing
between profiles
> Quick mount with breakaway tabs for alignment
> W x D x H: 35 x 12 x 100 mm (1 3/8" x 1/2" x 4")
> Material: PVC

Color Item No.
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
gray 793.00.004
Note
8 clips required per panel; for all slotted profiles.
→ Cover Brush

> Slides into slotted profile to conceal slots
> Width: 2800 mm (9' 2 1/4")

Color Item No.
gray 793.00.005
Note
For all slotted profiles.

www.hafele.com/us FC 4.59
