Connectors and Shelf Supports
Wall Mount Shelf Supports

Shelf Supports

> For concealed installation with screw mount plate and adjustment
> For shelf thickness: ≥24 mm
> Inclination adjustment: Via support bolt
Height adjustment: Via slots in screw mount plate
Side adjustment: Via support bolt
> For screw mounting to support element; for mounting in drilled
hole in shelf
> Material: Steel, galvanized; Wall plugs: Plastic

→ Shelf Support with Inclination Adjustment

44 Item No.
5
19.5 283.33.941
68 Supplied With 4 Plastic wall plugs, 4 Screws
82
Drilling and routing dimensions in shelf
Ø12 20

100 12
103 12
9.5
18.5 9 18.5 Ø12
12 100
23 112
Weight capacity (with two supports on 900 mm shelf, adding one
support for every 450 mm increase in length) 22
Shelf Depth Max. weight capacity 84
175 20 kg (44 lbs.)
200 17 kg (37 lbs.) 13
Connectors and Shelf Supports
225 15 kg (33 lbs.)
250 14 kg (31 lbs.)
275 13 kg (29 lbs.)
300 12 kg (26 lbs.)

→ Floating Shelf Extrusion Rail

13 8 mm
5.5 (1/2") 4
(1/4") (3/16")
1.75
(1/16") 7 mm
45°
19.5 (3/4") 16 (5/8") (1/4") (1/4") 16 (5/8") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
5.5
5.5
1.75
(1/16") → Hardware for Floating Shelf System
1.75
11 9 (3/8") (1/16") > For attaching shelf support to rail
11.3 (7/16") > Material: Steel

> Ideal for floating shelves combined with shelf support above
> Provides strength and stability over long spans Item No.
> Attaches to stud walls with #10 Pan head screws 020.92.761
> Can be cut and drilled Supplied With
> L x W x H: 2500 x 13 x 19.5 mm 4 – M5 x 12 mm screws
> Material: Aluminum, unfinished 4 – M5 weld nuts

Item No.
833.74.894
