Connectors and Shelf Supports
Wall Mount Shelf Supports

Shelf Supports

> Concealed mounting for floating shelf
> For material thickness: 40 mm
> Inclination adjustment: -8 to 20 mm via 10 mm spanner
Height adjustment: +/- 2.5 mm via slotted plate
Side adjustment: +/- 2.5 mm via locking screw
> Weight capacity: 20 kg per support for 200–400 mm shelf depth
> Material: Zinc/Steel

→ TRIADE MAXI Shelf Support

Item No.
Pan Head 283.39.012
#10

14 Ø5.5 62 3.6
49 (1 15/16") (9/16") (Ø3/16") (2 7/16") (1/8")
28.5 28.5
(1 1/8") (1 1/8")
10
(3/8") 74.5
150 (5 7/8")
(2 15/16")
R7.5
5 (3/16") (R5/16")
Ø26 40 min. 26 (1")
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
(Ø1")
52 1 Ø3.5 (Ø1/8")* 85
4 (2 1/16") (3 3/8") 4
(3/16") 73 * (3/16")
(2 7/8") *Optional drilling for securely locking with M4 grub screw
155 (6 1/8") placed underneath in alignment with the cavity
→ TRIADE Shelf Support - Maxi Bracket Connectors and Shelf Supports

> Provides extra support to TRIADE shelf supports
by providing 3 fixing points via Ø8 mm pin
and screw fix
> Material: Steel

Finish Item No.
62 Ø7 (1/4") zinc-plated 283.39.021
(2 7/16")
Supplied With
23.5 M5 x 12 mm screws
(15/16")
3.5
74.5 (1/8") 62 17.5 11
(2 15/16") (2 7/16") (11/16")
100 (3 15/16")
130 (3/16")
10 (3/8") Ø8
R 7.5 (R 5/16")
R 7.5 (R 5/16")
40 (5/16")
26 (1") (1 9/16")
min. 4 60
4 57 (3/16") (2 3/8")
85 (3 3/8") (3/16") (2 1/4")
140 (5 1/2") 160 (6 5/16")
Pan head screws pages 12.9-12.10
