Connectors and Shelf Supports
Wall Mount Shelf Supports
Shelf Supports
→ TRIADE Drilling Jig Kit
> Complete kit for TRIADE Mini, TRIADE and TRIADE Maxi
Item No.
356.12.091
Supplied With
Plastic case
TRIADE drilling jig
14 mm drill bit
Drilling jig for security locking
Template and spacer for TRIADE Mini, TRIADE and TRIADE Maxi
Aluminum profile
3.5 mm drill bit
Instruction book
4 mm hex key
Mounting screws
TRIADE drilling jig
for Ø14 mm hole
Template
Spacer
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Template for Alu profile
Drilling jig
Template for Alu profile
Drill bit Ø14 mm Connectors and Shelf Supports
Drill bit Ø3.5 mm
→ TRIADE Drill Bit
> Ø14 mm for shelf drilling
> Material: Steel
Item No.
001.41.364 11
