Connectors and Shelf Supports
Work Surface Brackets

SpeedBrace

> 19 x 38 mm (3/4" x 1 1/2") notching system for fast and easy
alignment after installing a level wall cleat
> Two different sized arm lengths, which allow for one brace to be
used for two different sized countertops
> Heavy-duty folded steel design for strength
> Two conduit holes, which are designed for running power and
communication cables independently
> Countersunk screw holes allow screws to be mounted flush,
recommended screw size is a #8 with a countersunk head
> Weight capacity: 454 kg (1,000 lbs.) per pair when mounted
on 16" centers
> Material: Steel, epoxy or stainless steel

→ Brackets

Finish L x W x H Item No.
Flat Head stainless steel 711 x 45 x 533 (28" x 1 3/4" x 21") 287.77.003
#8
black 711 x 45 x 533 (28" x 1 3/4" x 21") 287.74.307
white 711 x 45 x 533 (28" x 1 3/4" x 21") 287.74.707
black 610 x 45 x 533 (24" x 1 3/4" x 21") 287.74.305
white 610 x 45 x 533 (24" x 1 3/4" x 21") 287.74.705
stainless steel 457 x 38 x 381 (18" x 1 1/2" x 15") 287.77.002
black 457 x 38 x 381 (18" x 1 1/2" x 15") 287.74.304
white 457 x 38 x 381 (18" x 1 1/2" x 15") 287.74.704
stainless steel 305 x 38 x 203 (12" x 1 1/2" x 8") 287.77.001
black 305 x 38 x 203 (12" x 1 1/2" x 8") 287.74.301
white 305 x 38 x 203 (12" x 1 1/2" x 8") 287.74.701

Connectors and Shelf Supports

38 (1 1/2")
L
W 38 (1 1/2")

Recommended Countertop Sizes:
21" x 28" brace: 30"-32" tops H
28" x 21" brace: 22"-24" tops
15" x 18" brace: 20"-24" tops
18" x 15" brace: 16"-20" tops
8" x 12" brace: 10"-16" tops Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

11

Flat head screws pages 12.7-12.8, 12.10, 12.13
®
Snaptoggle bolts page 11.106
