Connectors and Shelf Supports
Work Surface Brackets

Centerline Countertop Support Brackets

> Designed to create a floating countertop effect
> Provides support for overhanging granite and stone
countertop surfaces
> Made in USA from domestically-sourced steel

→ Front Mounting Bracket

> Surface mount in vertical plate at stud location
> Supports overhang to 406 mm (16")
> Width x Thickness: 63 x 10 mm (2 1/2" x 3/8")
> Material: Steel, powder-coated; Finish: black

D x H Finish Item No.
254 x 203 (10" x 8") black 287.75.332
305 x 254 (12" x 10") black 287.75.333
3 (1/8")
D R: 356 x 254 (14" x 10") black 287.75.334
10 1 (1/16")
(3/8") 356 x 254 (14" x 10") white 287.75.734
35˚ Supplied With
Mounting screws
Connectors and Shelf Supports
H
21 (13/16")
35˚
10
3X 32 (3/8")
(3X 1 1/4")
→ Front Mounting Plus Bracket

25 (1")
64 > For floating countertops, vanities, shelves, benches and
(2 1/2") D 12 (1/2") 6
work surfaces
> Surface mount in vertical plate at stud location (1/4")
10 > Low-profile gusset feature for additional support
(3/8") > Supports overhang to 610 mm (24")
6 > Width x Thickness: 63 x 10 mm (2 1/2" x 3/8")
(1/4") H
> Material: Steel, powder-coated Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
21
(13/16")
D x H Finish Item No.
356 x 254 (14" x 10") black 287.75.313
3X 32
(3X 1 1/4")
11 64 25 (1") 406 x 305 (16" x 12") black 287.75.314
(2 1/2") D 12 (1/2") 6 467 x 305 (18" x 12") black 287.75.315
(1/4")
508 x 356 (20" x 14") black 287.75.316
10 508 x 356 (20" x 14") white 287.75.716
(3/8")
6 559 x 356 (22" x 14") black 287.75.317
(1/4") H 610 x 406 (24" x 16") black 287.75.318
21 Supplied With
(13/16")
Mounting screws
3X 32
(3X 1 1/4")
FC 11.137A www.hafele.com/us
