Connectors and Shelf Supports
Work Surface Connectors
Zipbolt
M
X
→ 10.900 Zipbolt Dogbone – UT
37 31 40 > (X) Shaft center = 5.5 mm (13/64")
(1 7/16") (1 1/4") (1 9/16") > (M) = Minimum bore depth: 12.5 mm (31/64")
> Material: Steel; Clamps: Zinc/Plastic
25
(1")
Ø6
(1/4") Item No.
262.96.945
Note
Requires 4 mm hex driver.
→ 10.800 Zipbolt Mini – UT
42-49 42-49 > (X) Shaft center = 5.5 mm (13/64")
(1 11/16"-1 7/8") (1 11/16"-1 7/8") > (M) = Minimum bore depth: 12.5 mm (31/64")
Ø25
(1") > Material: Steel; Clamps: Zinc/Plastic
Ø6 Item No.
(1/4") 262.96.946
Note
Requires 4 mm hex driver.
Connectors and Shelf Supports
→ Hex Key, 4 mm
> With hexagon socket head
> Material: Steel
Color Item No.
black 008.28.044
→ Hex Socket Bit
> 4 mm
> Material: Hardened Tool Steel Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Item No.
006.37.945
11 Supplied With
10 pcs.
