Connectors and Shelf Supports
Brackets

Connecting Brackets

→ Table Plate

17
1.5 > With screw hole and slot
(1/16") (11/16") 9 25 Pan Head > Material: Steel
(3/8") (1") #8
21
(7/8") 8 (5/16") Finish Item No.
5 nickel-plated 260.25.703
Ø5 (3/16")
(3/16")
→ Table Plate

17
1.5 (11/16") > With screw hole and slot
(1/16") 9 25 Pan Head > Material: Steel
(3/8") (1") #8
21
(7/8") 10 Finish Item No.
(3/8") nickel-plated 260.26.700
5 8
Ø5 (3/16") (5/16")
(3/16")
→ Corner Braces

A C > With screw holes
> Material: Steel; Finish: blue galvanized

A x B C D Item No.
B D
25 x 25 15 10 260.28.902
40 x 40 15 20 260.28.904
Flat Head
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
#8 2 50 x 50 15 25 260.28.905
(1/16") 60 x 60 18 32 260.28.906
80 x 80 18 46 260.28.908
→ Angle Bracket

27 12
(1 1/16") (1/2") > Material: Steel, epoxy-coated Connectors and Shelf Supports
Flat Head
7.8 #6
(5/16") Finish Item No.
27
(1 1/16") white 260.35.740
brown 260.35.140
7.8
(5/16")
2.3
(1/8")

11

Flat head screws pages 12.7-12.8, 12.10, 12.13
Pan head screws pages 12.9-12.10

www.hafele.com/us FC 11.69
