Connectors and Shelf Supports
Brackets
Connecting Brackets
→ Universal Brackets
> For 32 mm series holes
Side panel
> Material: Steel
15 37
Finish Item No.
galvanized 264.25.909
32 32 white epoxy-coated 264.25.703
32 32
VARIANTA
5 Ø5 Ø5
50 (2")
37 (1 1/2")
25 21 (7/8")
(1") 12 (3/8")
32 32
Ø7
(1 1/4") 42 (1/4") (1 1/4")
(1 11/16")
15 32 (1 1/4")
(9/16") 2 (1/16")
