Locks and Catches
Battery-operated Funiture Lock

EFL 30/30C furniture locks

132 (5 3/16") 12
125 (4 15/16") (1/2")
30
(1 3/16")
48 (1 7/8") 32 (1 1/4") 60 (2 3/8")

> Battery-operated, intelligent locker lock for indoor use:
for lockers, wood door cabinets and sliding doors
> Ideal for individual locking points and mobile furniture
> Integration into Dialock software or use of the Dialock Manager
app for convenient configuration and administration of locking
Technical Data points and locking authorizations
Technology Tag-It, Mifare Classic EV1, Mifare > Slim and compact design
Desfire EV1/EV2 > Integrated BLE module (Bluetooth Low Energy)
For start-up and configuration with > Material: Housing: Plastic;
Locking bolt and locking component: Zinc Alloy
the Häfele Dialock Manager app for
BLE (Bluetooth 5) integrated smartphones (available for iOS and > Color: Black
Android) > For door thickness: <19 mm (3/4")
Degree of protection IP20 Standard mode
2 x AAA battery, industrial alkaline, User keys are allocated to one or several (optional) locks for locking
Batteries
1.5 V and unlocking. The lock remains open for 3 seconds after opening,
Battery service life Up to 20,000 cycles then locks again automatically. The door status (locked/open) can be
Number of possible keys <1000 identified with the feedback contact and additional macro which can
trigger an alarm. The open time can be adjusted to 1–30 seconds in
Operating temperature 0 °C to +55 °C the basic operation mode using the programming transponder.
Humidity 10–95% not condensed Free choice of locker
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Card max. 38 mm (1 1/2") Every user key can lock an open locker. When opened, the user key
Read range
Tag max. 28 mm (1 1/8") is assigned to the selected locker; only this user key can unlock the
Minimum distance from EFL 30 100 mm (4") (vertical) locker. When the locker is unlocked, the assignment is deleted.
to EFL 30 150 mm (5 7/8") (horizontal) mounted The locker number is not stored on the user key.
Tensile load 1000 N Toggle mode (deadbolt lock function)
126 x 61 x 13 mm When an authorized transponder is held in front of the device,
Dimensions (L x W x D) (5" x 2 3/8" x 1/2") the lock unlocks and remains unlocked. When the user key is
presented again, the lock is locked.
CE (Europe), FCC (USA), Note
Approvals and certifications IC (Canada), The EFL 30 / EFL 30C can be configured and operated in the
EN 61000-4-2 – level 3 standalone mode via the Dialock Manager app or as locking point
Note in the Dialock Software using the programming card and clearing
In order to avoid interference between locks, a minimum distance of key card.
100 or 150 mm (4" or 5 7/8") must be maintained between installed
locks. If the distance is less than this, continuous communication will 10
take place between the locks, which will drain the battery. In order Version Item No.
to avoid unnecessary battery drainage, do not insert the battery until EFL 30 furniture lock 237.59.070
start-up takes place. For applications that require a smaller distance, EFL 30C lock with additional feedback contact 237.59.071
the FT 200 can be used in combination with the EFL 3 instead.

Installation of hinged door: Locks
In order to unlock the EFL 30, the transponder card must be held
against the hinged door.
Installation on cabinet:
In order to open the EFL 30, the transponder card must be held
against the side of the cabinet.
Installation on drawer:
In order to open the EFL 30, the transponder card must be held
against the side of the cabinet.
Note
Please order batteries (Item No. 910.54.953) separately.
Please order programming and clearing key card, Dialock Manager
app license or software separately.
