Locks and Catches
Cabinet Locks

SYMO 3000 Modular Removable Core Locking System

→ STW Pin-Tumbler Cylinder Removable Core → Cylinder Rosette

15.5 25 Ø19
(9/16") (15/16") (3/4")
2
Ø12.5 (1/16")
(1/2") Ø25
5 (1")
(3/16")
> 19 mm (3/4") hole required
> Press-fit
> Locking system: with 6 pairs of pins > Material: Steel
> Key changes: 10,000 different key changes are possible
> Key type: dimple key Finish Item No.
> Material: Zinc Alloy
nickel-plated matt 219.19.676
Finish Item No. → Special Drill Bit
nickel-plated 210.45.600
Supplied With
1 Key
Note
Master keying and General Master key systems available upon request.
Verify production time. Ø19
(3/4")
→ STW Pin-Tumbler Cylinder Removable Core
keyed alike > Ø18 mm (11/16") is suitable for any cylinder housing in the
SYMO system
> Ø19 mm (3/4") is suitable for rosette application
Key Change Item No. > Material: Shank: Steel; Bit: Carbide-tipped
001 A 210.45.601
002 A 210.45.602 Diameter Item No.
003 A 210.45.603 18 (11/16”) 001.06.365
004 A 210.45.604 19 (3/4”) 001.08.014
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
005 A 210.45.605
Supplied With
1 Key
→ Removal Key

> For pin-tumbler cylinders/dimple key 10
> Material: Steel

Finish Item No.
Locks
nickel-plated 210.45.090
