Locks and Catches
Cabinet Locks

Anti-Tip System

> Meets or exceeds ANSI/BFIMA requirements
> Only one drawer can be opened at a time

→ Anti-Tip Snapper

> Mounts to side of cabinet
Pan Head > Material: Zinc die-cast, unfinished
#8
64
(2 1/2")
32 Finish Timberline No. Item No.
(1 1/4") Note SN-400 237.43.310
black
152 (6 1/16") 32 (1 1/4") 41 (1 5/8") 1 required for 2 drawers.

→ Drawer Clips, standard

> Mounts to side of drawers
Pan Head > Material: Plastic
#8 32 46
(1 1/4")
(1 3/4")
Finish Timberline No. Item No.
32 black DC-400 237.43.320
(1 1/4")
46 Note
(1 3/4") 2 required per snapper.
→ Drawer Clips, narrow

25 (1")
> Mounts to side of drawers
Pan Head > For use when there is less space between drawer slides
#8 38 > Material: Plastic
(1 1/2")
64
77 (2 1/2")
(3 1/16") Finish Timberline No. Item No.
black DC-410 237.43.322
10 13 Note
2 required per snapper.
(1/2")
→ Linkage Arm Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Locks 19 > Material: Plastic

21
(7/8") (3/4")
Color Timberline No. Item No.
48 (1 7/8") black SN-410 237.43.330
Note
2 pcs. required for 4 drawers.

Pan head screws pages 12.9–12.10
