Hinges and Stays
Lid and Flap Stays

Häfele Duo Standard/Duo Forte

→ Individual Fitting

> For left and right hand use
> Without tools (clip-on system) onto pre-mounted mounting
bracket
> Adjustment facility: Holding power
> Material: Zinc Alloy
Duo
Standard Duo
Forte
Model nickel-plated white black silver
series
Standard 373.66.500 373.66.250 373.66.200 373.66.800
Forte 373.66.700 373.66.350 373.66.300 373.66.900
Supplied With
Lid stay
Mounting instructions
Note
→ Mounting Bracket for Cabinet Mounting brackets and screw-on bracket are not supplied.
Please order separately.
For edge For edge
distance distance → Mounting Bracket for Wood or Aluminum Frame Door
37 mm 28 mm
(1 1/2") (1 1/8")
Wood Screws Euro Screws
2 2
(1/16") (1/16")
6.5
(1/4")
6.5
(1/4") 32.5 27
41.5 (1 1/4") (1 1/16")
(1 5/8") 19.5 12.5
(3/4") 20
17.5
(1/2") (13/16") (11/16") Ø5
32 14.5 32 Ø6.3 (3/16")
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
17
32 14.5 (1 1/4") (9/16") (1 1/4") (1/4") (11/16")
(1 1/4") (9/16") 45 16.6
45 (1 3/4") (5/8") 15
(1 3/4") (9/16")
45
(1 3/4")
> For mounting the lid stay to the cabinet
> Material: Steel
> Screw mounted
> For mounting the lid stay to the door 9
For edge nickel- > From frame width: 45 mm (1 3/4")
distance plated white black silver > Material: Steel
(cabinet)
28 (1 1/8") 373.66.693 373.66.395 373.66.393 373.66.993 nickel-
37 (1 1/2") 373.66.694 373.66.396 373.66.394 373.66.994 Installation plated white black silver
Wood screws 373.66.681 373.66.384 373.66.381 373.66.981
→ Special Door Mounting Bracket Euro screws 373.66.036 373.66.386 – – Hinges and Stays
45 → Mounting Bracket for Aluminum Frame Door
(1 3/4")
32
(1 1/4")
4 > From frame width: 20 mm (13/16")
(3/16") 17
(11/16")
nickel-
13 Installation white
(1/2") plated
Sheet metal screws 373.66.682 373.66.385

> For use with a face frame overlay 5-piece door
> Material: Steel

Finish Item No.
nickel-plated 373.66.685

www.hafele.com/us FC 9.141
