Drawer Slides
Ball Bearing

Accuride Full Extension, Telescopic, Self-closing

→ 3834ESC Side Mounted

> Weight capacity: 41 kg (90 lbs.)/pair
> For drawers: max. 600 mm (24") wide
> Use in retail displays and institutional fixtures
> Self-closing
> Lever disconnect
> 1" overtravel
> Material: Steel, electro-plated

Installed length B Extension length Item No.
350 (14") - 381 (15") 422.86.936
400 (16") - 432 (17") 422.86.941
450 (18") 320 (12 5/8") 483 (19") 422.86.946
500 (20") - 533 (21") 422.86.951
550 (22") 416 (14 3/8") 584 (23") 422.86.956
VARIANTA Pan Head
5 #8 600 (24") 416 (14 3/8") 635 (25") 422.86.961
35
(1 3/8") Slide
length
35 13
(1 3/8") (1/2")
45.5 B 224
(1 13/16") 12.7 224 (8 13/16") 9 (8 13/16") 13 11
(1/2") (1/8") 128 (1/2") (7/16")
128 (5 1/16") 13
(5 1/16") (1/2")
46
12.7 (1 13/16") PAT.5255983
(1/2") 61
9 (2 3/8") 22 (7/8")
(1/8") 34
( 1 3/8")
8 → Face Frame Bracket Kit, optional

> Material: Steel Item No.
Drawer Slides Ø4.6 (3/16") 8 (5/16") Supplied With 422.04.000
Finish
Front
zinc-plated
clip-on bracket
2 Front/rear brackets

31.8
37.8
(1 15/16")
6.4 48.5 (1 1/4") (1 1/2")
(1/4") 15.9 (5/8")
4.6 x 7.1
(3/16" x 1/4") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

Pan head screws pages 12.9-12.10
Varianta screws page 12.16
