Drawer Slides
Ball Bearing

Accuride Full Extension, Telescopic

> Weight capacity max.: 45 kg. (100 lbs.)/pair
> For drawers: max. 610 mm (24") wide
> Hold-in detent
> Lever disconnect
> BHMA and AWI certified to Grade 1 HD-100
> Material: Steel, electro-plated

→ 3832E Side Mounted

37 (1 29/65")
37 (1 29/64") Cabinet front edge 32
28 (1 17/64")
(1 7/64") Installed length
2
(5/64") 35
(1 3/8") 128 96 A
2 (5 1/32") (3 25/32")
(5/64")

35
(1 3/8")
B
Extension length
Pan Head VARIANTA
#8 5
45.5
(1 13/16")

For optimal performance, construct drawer 12.7
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
27 mm (1 1/16") less than cabinet opening. (1/2") 8
Installed and extension length Shop pack zinc Bulk pack zinc Bulk pack black Bulk pack white FP pack zinc
150 (6") 422.04.152 - - - -
200 (8") 422.04.203 - - - -
250 (10") 422.04.258 422.04.259 422.04.268 422.04.277 422.04.925
300 (12") 422.04.301 422.04.302 422.04.311 422.04.320 422.04.930
350 (14") 422.04.356 422.04.357 422.04.366 422.04.375 422.04.935 Drawer Slides
400 (16") 422.04.401 422.04.400 422.04.419 422.04.428 422.04.940
450 (18") 422.04.454 422.04.455 422.04.464 422.04.473 422.04.945
500 (20") 422.04.507 422.04.508 422.04.517 422.04.526 422.04.950
550 (22") 422.04.552 422.04.553 422.04.562 422.04.571 422.04.955
600 (24") 422.04.605 422.04.606 422.04.615 422.04.624 422.04.960
650 (26") 422.04.650 422.04.651 422.04.660 422.04.679 422.04.965
700 (28") 422.04.703 422.04.704 422.04.713 422.04.722 422.04.970
Supplied With Shop Pack: 1 pair, Screws and Instructions; FP Pack: 10 pairs, separated, Bulk Pack: 10 pairs

→ Face Frame Rear Brackets, optional
Front
clip-on bracket
Ø4.6 (3/16") > Material: Steel
8 (5/16")
48.5 31.8 Finish Item No.
37.8
(1 15/16") (1 1/4") (1 1/2") zinc-plated 422.59.002
6.4 Note
(1/4") 15.9 (5/8") 2 pcs required per slide
4.6 x 7.1
(3/16" x 1/4")
Pan head screws pages 12.9-12.10
Varianta screws page 12.16

www.hafele.com/us FC 8.87
