Drawer Slides
Ball Bearing

Accuride Full Extension, Telescopic, Self-closing

> Weight capacity: 45 kg (100 lbs.)/pair
> For drawers: max. 600 mm (24") wide
> Self-closing feature closes drawers and keeps them closed
> Lever disconnect
> Strong pull out force is required to open drawers
> Material: Steel, electro-plated or epoxy coated

→ 3832ESC Side Mounted

VARIANTA
5
Slide length
35 13
(1 3/8") 224 (1/2")
12.7 B 9 (8 13/16") 13 11
(1/2") 35 (1 3/8") 224 (8 13/16") (3/8") 128 (1/2") (7/16") 13
128
(5 1/16") (5 1/16") (1/2")
46
(1 13/16") PAT.5255983
61
9 (2 3/8") 34 22 (7/8")
Use round (1/8") ( 1 3/8")
hole for final
mounting
Mount through horizontal Drawer member
slots first Vertical slots
1 1/4" For optimal
performance,
1 1/2" construct drawer
27 mm (1 1/16")
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
1/8" Disconnect lever less than cabinet
2 3/8" Cabinet 1/4" opening. 8
member
Shop pack Bulk pack Shop pack Bulk pack Shop pack Bulk pack
Installed and extension length B
zinc zinc black black white epoxy white epoxy
300 (12") 422.59.930 - - - - -
350 (14")* 422.59.935 422.59.936 422.59.335 422.59.336 - 422.59.736
400 (16") 422.59.940 422.59.941 422.59.340 422.59.341 422.59.740 422.59.741 Drawer Slides
450 (18") 320 (12 5/8") 422.59.945 422.59.946 422.59.345 422.59.346 422.59.745 422.59.746
500 (20") 422.59.950 422.59.951 422.59.350 422.59.351 422.59.750 422.59.751
550 (22") 416 (16 3/8") 422.59.955 422.59.956 422.59.355 422.59.356 422.59.755 422.59.756
600 (24") 416 (16 3/8") 422.59.960 422.59.961 - - - -
650 (26") 416 (16 3/8") 422.59.965 422.59.966 - - - -
Supplied With Shop Pack: 1 pair, Screws, Instructions; Bulk Pack: 10 pairs
Note *Travel on the 350 mm (14") is 307 mm (12 1/16").
→ Face Frame Rear Brackets, optional
Front
clip-on bracket
Ø4.6 (3/16") > Material: Steel
8 (5/16")
Finish Item No.
48.5 31.8
37.8
(1 15/16") (1 1/4") (1 1/2") zinc-plated 422.59.002
6.4
(1/4") 15.9 (5/8")
4.6 x 7.1
(3/16" x 1/4")

Varianta screws page 12.16
