Drawer Slides
Single-Wall Drawer System

Grass Zargen

→ 6035

B = A - Slide constant > Side height: 43 mm (1 11/16")
Drawer > Material: Steel; Finish: white
front Centerline of
cabinet member Length Item No.
Slide constant 17.8 (11/16") A 350 (13 3/4") 558.26.835

558.26.840
400 (15 3/4")
(1 1/4")
6.5 B
32
(1/4")
470 (18 1/2")
558.26.847
Min. 21 440 (17 3/8") 558.26.844
Min. 14 Min. 28 (13/16") 510 (20 1/16") 558.26.851
Top panel (9/16") (1 1/8") 550 (21 5/8") 558.26.855
Supplied With
5 sets
Min. 10
43 Side (13/32") Min. 4 *33.5
(3/16")
(1 11/16") 9.5
(3/8") (1 5/16")
1 mm 11.7 (7/16")
beveled 45° Bottom
panel width
15.5 15.5
(5/8") = ICW - 31 (1 1/4") (5/8")
Tolerance
adjustment
2 (1/16")
Inside cabinet width
(ICW)
→ Spare Guide Clip
> Material: Steel
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
8
Finish Item No.
white 558.19.291
Drawer Slides
→ Rear Mounting Bracket

> Material: Plastic

Handing Item No.
Right 433.19.054
Left 433.19.055
Supplied With
100 pcs.

→ 6036 Router Bit for Zargen and Z Box

> Designed for grooving and beveling the drawer bottoms for the
lipped version of the Zargen and Z Box drawer slides
> 13 mm (1/2") shank

Item No.
558.18.992
