Drawer Slides
Double-Wall Drawer System

Grass Nova Pro Scala

Note
See required
slides on
next page.

→ H186 Series → H250 Series

> Slim, deep drawer side > Slim, deep drawer side
> Side height: 186 mm (7 5/16") > Side height: 250 mm (9 13/16")

Length stone ice silver Length stone ice silver
300 (12") 551.84.530 551.84.730 551.84.930 400 (16") 558.81.563 558.81.763 558.81.963
350 (14") 551.84.535 551.84.735 551.84.935 450 (18") 558.81.564 558.81.764 558.81.964
400 (16") 551.84.540 551.84.740 551.84.940 500 (20") 558.81.565 558.81.765 558.81.965
450 (18") 551.84.545 551.84.745 551.84.945 550 (22") 558.81.566 558.81.766 558.81.966
500 (20") 551.84.550 551.84.750 551.84.950
550 (22") 551.84.555 551.84.755 551.84.955

→ Front Installation Brackets → Front Fixing Brackets
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
8

Drawer Slides

> For use with H186 and H250 series

Mounting Item No.
> For use with H186 and H250 series Screw 551.90.932
Dowel, 10 mm (3/8") 551.90.952
Note
Mounting Item No. 2 clips are required per drawer.
Screw 551.90.901
Dowel, 10 mm (3/8") 557.99.911
→ Front Stabilizer Button
Note
2 brackets are required per drawer.
> Required for H250 height

Item No.
551.90.659
Note
2 pcs. are required per drawer.

Required slides page 8.36

www.hafele.com/us FC 8.35
1/22
