Sliding and Roller Shutter Systems
Coplanar Doors

HAWA Frontino 40 FB

> Door weight: max. 40 kg (88 lbs.)
> Door height: max. 2380 mm (93 11/16")
> Door width: 587–1197 mm (23 1/8"–47 1/8")
> Door thickness: 19 mm (3/4")
> Handle height: max. 30 mm (1 3/16")
> Doors slide smoothly and quietly and sit flush when closed
> Integrated soft close prevents slam

Note
Both doors must have the same dimensions. Door width in the order
table is with one side.

Version Cabinet width Door width Fitting set Track set
1200–1799 (47 1/4"–70 13/16") 594–893 (23 3/8"–35 3/16") 406.02.032 406.02.613
For 2 sliding doors 1800–2199 (70 7/8"–86 9/16") 894–1093 (35 3/16"–43 1/16") 406.02.033 406.02.614
2200–2400 (86 5/8"–94 1/2") 1094–1194 (43 1/16"–47") 406.02.034 406.02.615
7
Installation and drilling guide (top)
A Reference
J
Sliding and Roller Shutter Systems
Y = G + 168 / 318 / 418 Z = G + 128 / 278 / 378 Cabinet width A
(6 5/8" / 12 17/32" / 16 15/32") (5 1/32" / 10 15/16" / 14 7/8") Door width B
Door height C
Drilling distance,
drive to center front G
Height H
104 Side panel thickness K
(4 3/32")
Cabinet height KH
Door recess (3 mm) L
2 x Z x 35 (1 3/8")
70 Base height M
(2 3/4")
A Drilling position
K 53 J K of radial cam Y
290 / 440 / 540 (2 3/32")
(11 13/32" / 17 5/16" / 21 1/4") Edge position Z
of radial cam Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

L L
A - 6 - (2 x L)
B = 62 43 6 (1/4")
2
(2 7/16") (1 11/16") B 65
(2 9/16")
