Casters, Feet, Legs, Table Fittings
Table Legs

KOYO Adjustable System

→ Leg Ø60 mm → Caster with brake Ø60 mm

Pan Head
#10
12 (1/2")

Ø60
(2 3/8")
Note 77 - 89
Legs are conveniently marked with (3 1/16" + 3 1/2")
a scale to keep track of height level.
Leveler plus spacer equals the same Shown with caster option
height as casters 77 mm (3 1/16").
> Ø x H: 60 x 77 mm (2 3/8" x 3 1/16")
60° > Casters are adjustable up to 12 mm (1/2") for leveling tables on
6 (4 1/8") (4 3/4") uneven floors
120
> Leveler plus spacer equals the same height as casters
105
> Material: Plastic
20 (13/16") 300 (11 3/4") of height adjustment Ø7 (1/4") x 6 places Color Item No.
Casters, Feet, Legs, Table Fittings
120
635.01.004
black
(4 3/4")
→ Leveler
20 (13/16") Ø43 (1 11/16") (1 1/16")
27

630 (24 3/4") > Height: 10 mm (3/8")
Ø60 705 + 12 (27 3/4" + 1/2") of leveling adjustment
(2 3/8") 640 + 12 (25 3/16" + 1/2") of leveling adjustment

10 (3 1/16" - 3 1/2") > Material: Plastic; Color: black
(3/8") 77 - 89 Ø Item No.
Shown with leveler option 60 (2 3/8") 635.01.001
Ø60 or Ø90 (2 3/8" or 3 9/16") Shown with spacer 90 (3 1/2") 635.01.002
and leveler option
Ø60 (2 3/8")
→ Spacer
> Meets or exceeds ANSI/BIFMA requirements
> Please note that each leg must be adjusted separately
> Static weight capacity exceeds 227 kg (500 lbs.) per leg
> Ø: 60 mm (2 3/8")
> Height adjustment: 300 mm (11 3/4") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
> Minimum height with leveler installed: 640 mm (25 3/16")
> Maximum height: 940 mm (37"); spacers/casters add to
this height accordingly
> Material: Legs: Steel, epoxy-coated
Mtg. plate & inner column: Steel, chrome-plated

Finish Item No. > Ø: 60 mm (2 3/8")
silver/aluminum RAL 9006 635.01.271 > Height (leveler): 67 + 10 mm = 77 mm (2 5/8" + 3/8" = 3 1/16")
> Material: Plastic
Supplied With
4 Legs, 4 Mounting plates
Note Color Item No.
Mounting screws not included. 6 pcs. per leg required. black 635.01.003
Levelers, spacers, and casters are sold separately.

Pan head screws pages 12.9-12.10
