Casters, Feet, Legs, Table Fittings
Adjustable Table System – Side Mount Systems

Adjustable Columns

→ Double Column Side Mounted System

> Screw mounts between two side panels
> Has an adjustable support channel, width adjusts
from 1080–1803 mm (42 1/2"–71")
> With 4-setting programmable switch
> Has 3-stage adjustable columns
> Height range: 530–1197 (20 7/8"–47 1/8"), not including top
thickness
> Stroke: 667 mm (26 1/4")
> Travel speed: 40 mm (1 1/2") per second
> Weight capacity: 127 kg (280 lbs.) including work surface
> Material: Steel, epoxy-coated

Finish Item No.
silver RAL 9006 637.45.294
black RAL 9011 637.45.295
Supplied With
2 adjustable columns with welded on mounting brackets 6
Top supports and adjustable support channel
Double port control box
Programmable switch
Wiring and assembly hardware

667 (26 1/4")

Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
1198.8 (47 3/16") 1065.1 (41 15/16") Casters, Feet, Legs, Table Fittings

531.8 (20 15/16")

1080–1800 (42 1/2"–71")

1080–1800 (42 1/2"–71") 37 37 575 (22 5/8")
(1 7/16") (1 7/16")
137
(5 3/8") 51
(2")
203.2
137.1 (8")
Ø4.8
(5 3/8") (Ø3/16")
37.9 (1 1/2") 203.2 531.8 (20 15/16")
(8")
50 (1 15/16") 111.4 (4 3/8")

www.hafele.com/us FC 6.61
