Casters, Feet, Legs, Table Fittings
Table Legs

Stainless Steel

> High quality 304 grade brushed stainless steel
> Applications: kitchens, bathrooms, garage, boats, laboratories
and coastal environments where there is potential for moisture
> All legs have a wall thickness of 1.5 mm (1/16")

→ Table Leg → Anchoring Foot, optional

M10 - 1.5 41 50 6
(1 5/8") (2")
4
(3/16")
Ø85
Round (Ø3 3/8") 9
Ø75 (Ø3") (3/8")
Square
80 (3 3/16") > Non-adjustable foot allows for permanent anchoring of table leg
H series (round and square).
1.5 > Ideal option for supporting solid surface tops when both upper
(1/16") and lower portion of the leg needs to be anchored securely
> Material: Stainless Steel
Adjustment
9 Item No.
(3/8")
635.70.093 Casters, Feet, Legs, Table Fittings
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
16 → Mini Leg
(5/8")
M10 - 1.5
90
47 (3 9/16") Ø6
(1 7/8") 16 (Ø1/4")
(5/8") 17
(11/16")

150 (3 9/16") 90
10 (5 7/8") 10 Ø7 (Ø1/4") THRU
(3/8") (3/8") Ø12 (Ø1/2") x 90°
40 75 10 70 10
(1 9/16") (2 15/16") 170 (3/8") (2 3/4") (3/8")
(6 11/16")
75
Ø6 (Ø1/4") THRU 3
Ø12 (Ø1/2") x 90° (2 15/16") 1.5 (1/8")
(1/16") H
170 Ø9 (Ø3/8") THRU M10 - 1.5 Adjustment
(6 11/16") Ø16 (Ø5/8") x 90° 9
31 (3/8")
12.5
> An optional (non-adjustable) foot is available if permanent (1 1/4”) (1/2”)
anchoring of leg is required, to the right 14 Ø50
> Available in three heights; dining, counter or bar heights (9/16”) (2")
> Adjustable leveler offers 10 mm (3/8") of adjustment
> Material: Legs: 304 Stainless Steel > 50 mm (2") square or round cross section
Mounting Plate: Steel; Finish: black powder-coated > Adjustable leveler offers 10 mm (3/8") of adjustment
> Material: Legs: 304 Stainless Steel
Mounting Plate: Steel; Finish: black powder-coated
Round Round Square Square
Height Ø60 mm Ø75 mm 50 mm 80 mm
(2 3/8") (3") (2") (3 3/16") Height Round Square
716 (28 3/16") 635.70.003 635.70.000 635.70.013 635.70.010 100 (4") 635.70.020 635.70.030
883 (34 3/4") 635.70.004 635.70.001 635.70.014 635.70.011 152 (6") 635.70.021 635.70.031
1035 (40 3/4") 635.70.005 635.70.002 635.70.015 635.70.012 203 (8") 635.70.022 635.70.032
Supplied With Supplied With
Leg, Mounting plate, Adjustable leveler Leg, Mounting plate, Adjustable leveler

www.hafele.com/us FC 6.53
