Casters, Feet, Legs, Table Fittings
Table Legs

Folding Table Legs

> Folding table mechanism for conference rooms, training
centers, etc.
> Tables can nest together for storage
> Folds by pulling on lever bar
> Heavy duty, 150 kg (330 lbs.) weight capacity
> With 4 Ø75 mm braking casters
> Certified to European DIN EN 527-2 standard
Please order 3 parts:
1) Item 642.90.300 – feet, casters, components,
assembly hardware
2) Item 642.90.350 – vertical tubes
3) Choose appropriate length of horizontal stretcher
Note
Table top not supplied

→ Feet, Casters, Components, Assembly Hardware

> Material: End Frame: Zinc Alloy; Casters: Plastic 6
Finish/Color: End Frame: stainless steel effect;
Casters: black

Item No.
642.90.300

→ Vertical Tubes
49 (1 15/16")
> Material: Steel; Finish: black, powder-coated
LEVER 70 (2 3/4")
BAR Item No. Casters, Feet, Legs, Table Fittings
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
(10 3/4") Supplied With 2 pcs. 642.90.350
272 700–800 (27 1/2"–31 1/2") → Horizontal Stretcher

> Material: Steel; Finish: black, powder-coated
66 (2 5/8") 66 (2 5/8")

Length Item No.
680 (26 3/4") 642.90.370
880 (34 5/8") 642.90.371
HORIZONTAL
STRETCHER 1080 (42 1/2") 642.90.372
VERTICAL
TUBES
Dim. A
340 Recommendations Dim. B Dim. C Dim. D Dim. E
(13 3/8")
1023 mm–1222 mm 680 mm 898 mm 1023 mm 323 mm
(40"–48") (26 3/4") (35 5/8") (40") (12 3/4")
1222 mm–1423 mm 880 mm 1098 mm 1222 mm 422 mm
143 (48"–56") (34 5/8") (43 1/4") (48") (16 5/8")
(5 3/8")
1423 mm–1622 mm 1080 mm 1298 mm 1423 mm 523 mm
(42 1/2")
(51 1/8")
(56")
(20 5/8")
(56"–72")
710 (28") 1079 (42 1/2")

556 (22")
