Casters, Feet, Legs, Table Fittings
Casters

Casters

→ Roller-Mini Combined Glide/Swivel Caster

Ø54 > For applications that normally would require a glide
(2 1/8") > Caster wheel is used on hard surfaces; Glide is used on carpet
Ø40 > Material: Plastic; Color: black
(1 5/8")
17.2 25
(11/16") (1") Wheel/Color Item No.
Ø15 Hard/white 661.04.327
(9/16")
→ Ball Casters

> With screw-on mounting plate and reinforced base
> The ball casters can be moved in any direction
> Caster can be used as a conveyor system for transporting heavy
loads when mounted upside down
> Material: Steel; Finish: Housing: yellow chromate;
Ball: chrome-plated
6

Ball Installation Screw
Casters, Feet, Legs, Table Fittings
Ø height hole Ø
Mounting plate Ø
Ball Ø Approx. weight Installation Insert Insert Mounting Screw Item No.
capacity per caster height part Ø depth plate Ø hole Ø
13 (1/2") 6 kg (13 lbs.) 10 (3/8") 16 (5/8") 5.5 (3/16") 25 (1") 2 (1/16") 661.02.210
20 (13/16") 12 kg (26 lbs.) 15 (9/16") 23.5 (15/16") 8.5 (5/16") 35 (1 3/8") 3 (1/8") 661.02.230
25 (1") 17 kg (37 lbs.) 20 (13/16") 33 (1 5/16") 12 (1/2") 45 (1 3/4") 3 (1/8") 661.02.250 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

FC 6.14 www.hafele.com/us
