Page 439 - Furniture Cabinetry Hardware-FloorKitchenResource.com

Casters, Feet, Legs, Table Fittings
Casters

Casters

> White hard wheel for soft floors such as carpet
> Gray soft wheel for hard floors such as wood
> Weight capacity: approximately 50 kg (110 lbs.) per caster

→ Roller-Mini Swivel Caster

Ø54 > Moves and swivels furniture discreetly and elegantly
(2 1/8") > Only 7 mm (1/4") from floor, making any furniture mobile
Ø40
(1 5/8") > Material: Plastic; Color: black
17.2 25
(11/16") (1")
Ø15 Wheel/Color Item No.
(9/16") Hard/white 661.04.309
Soft/gray 661.04.340

→ Roller-Mini Fixed Caster

Ø54 > Same design as above in a fixed version 6
(2 1/8")
Ø40 > Moves in only one direction
(1 5/8") > Material: Plastic; Color: black
17.2 25
(11/16") (1")
Ø15 Wheel/Color Item No.
(9/16") Hard/white 661.04.318
Soft/gray 661.04.320

→ Roller-Mini Swivel Caster with Retractable Wheel

40
(1 9/16") 8 > Retractable wheel allows furniture to brake under weight:
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
benches, ottomans, stools, etc.
17 (11/16") (5/16") > Wheel retracts at a weight of 15 kg (33 lbs.)/caster or 45 kg Casters, Feet, Legs, Table Fittings
(100 lbs.)/caster
> Material: Plastic; Color: black
Ø54
15 (Ø2 1/8")
(9/16") Wheel/color Item No.
Braking function at 15 kg (33 lbs.)
Hard/white 661.04.351
Soft/gray 661.04.361
Braking function at 45 kg (100 lbs.)
Hard/white 661.04.352
Soft/gray 661.04.362

→ Mini Roller Caster
36
(1 7/16") > Weight capacity: 40 kg (88 lbs.) per caster
> Material: Plastic; Color: black
(9/16")
15
(1/2") Wheel/Color Item No.
13 Hard/white 661.05.320
27 Soft/gray 661.05.330
(1 1/16")

www.hafele.com/us FC 6.13
