Locks and Catches
Cabinet and Locker Locks

StealthLock - Battery Powered Electronic Locking Systems

> StealthLock electrically controls cabinet doors and drawers.
> It operates in passage or cycle modes, and is released with
an RF controlled key pad transmitter.
Features
> One key pad transmitter can activate an unlimited number of
locks within a 4.5 m (15 ft.) range
> Lock powered by 4–AAA batteries (not included)
> Low battery indicator on key pad transmitter and lock
> Meets ANSI/BIFMA 50 lbf. pull strength specifications
> Slim design mounts in 1/2" drawer suspension clearance
> For left or right hand operation
> Toggle lock or timed unlock delay
Areas of Application
> For interior use
Cabinet > For installation in wood, laminate or plastic cabinets and drawers
Technical Data:
Tensile load limit: 445 N. (100 lbf.)
19 Environmental: Operating temperature: 10º–49º C
(3/4") (50º–120º F)
Typical overlay door 8 Humidity (operating): 95%
86 (3 3/8") (5/16") Electrical: Supply voltage: 6 VDC (4 - AAA batteries,
sold seperately)
19
(3/4") 38 (1 1/2") Connections: Battery pack, self-contained
Door Battery Life: 4000 lock cycles
Standards Compliance: FCC
Key Pad Transmitter 11
(7/16") Solutions Available
172 (6 3/4")
> Standard: For most general office or residential applications.*
28 > Dedicated: For projects; Ideal for assigned lockers and
(1 1/8") fitness lockers.**
32 (1 1/4") 64 (2 1/2") Modes Available – Both Solutions
> Self-Lock Mode (Cycle)
9 > Passage/Manual Lock Mode (toggle)
(3/8") > Single Use Mode (day use)
Door Strike Plate Receiver Latch
→ Battery Powered RF Cabinet Lock Set

> Material: Receiver, Latch and Key Pad: Plastic
Door Strike Plate: Steel

Color Item No.
black 237.56.350
Supplied With
Installation tool
Mounting screws
10 Instructions Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

Locks → StealthLock-Loox Power Cord → Battery Powered RF Cabinet Lock with Strike Plate

> Material: Plastic > Material: Receiver and Latch: Plastic
Color: black/red/gray Door Strike Plate: Steel; Color: black

Length Item No. Color Item No.
1524 (60") 237.56.380 gray 237.56.352
3048 (120") 237.56.381 Supplied With
Mounting screws
Note
Programming cabinet lock 237.56.352 with dedicated key pad 237.56.171
will link or "marry" key pad and lock together for dedicated use.
FC 10.72 www.hafele.com/us
