Locks and Catches
Cabinet and Locker Locks

RegulatoR Battery Powered Electronic Locking System
®

→ Regulator Keypad Lock

> CompX RegulatoR is a lock used to electrically control cabinet
doors, drawers and lockers
> Depending on the model, this lock operates in an assigned use
or in a single use mode
> The lock is electrically released with a correct PIN code entered
on the keypad
Applications
> Cabinet doors or drawers
> Lockers
> Storage enclosures
> File cabinets
> Computer server racks
Markets
Manual Self > Healthcare
Lock Lock > Schools/universities
> Laboratory
> Office furniture
VERTICAL > Retail displays
mount
RegulatoR Features - Self-locking
38 > Self-locking, featuring SlamCAM
LEFT hand mount RegulatoR (1 1/2") > Spacers provide additional latching dimensions
> 50,000 cycles
38 35
(1 1/2") (1 3/8") > Convenient external battery installation/removal
> Low battery indicator
> Easy to clean membrane keypad
138
(5 7/16") > 19 user codes and 1 supervisor code
> Lock complies with ADA standards for door locks
RIGHT hand mount RegulatoR 138 > Lock is easily programmed by user with easy to use keypad
(5 7/16") > Lock mounts vertically for raised panel doors
35 38 > Designed to pass the ANSI/BIFMA 50 lbf. pull strength
(1 3/8") (1 1/2")
> Assigned use mode only
138 Features - Manual locking
(5 7/16") > 50,000 cycles
> Convenient external battery installation/removal
35 > Low battery indicator
(1 3/8") > Uses existing CompX National cams with FlexaCam
> Single use mode, or assigned use mode
> Cylinder length: 30 mm (1 3/16") > Easy to clean membrane keypad
> Material: Lock body: Aluminum; Color: gray > 19 user codes and 1 supervisor code
Face plate: Plastic; Cam: Steel / Plastic > Lock complies with ADA standards for door locks
> Lock is easily programmed by user with easy to use keypad
> Lock mounts vertically for raised panel doors
Lock orientation Handing Manual lock Self-lock > Designed to pass the ANSI/BIFMA 50 lbf. pull strength
Horizontal, lever on left RH 231.97.003 231.97.103 Specifications
10 Horizontal, lever on right LH 231.97.013 231.97.113 > Long battery life (10 lock cycles per day for four years)
> Easy installation with only two drill points
RH/LH
Vertical, lever on bottom
231.97.153
231.97.053
Supplied with > For left and right hand operation
1 Straight cam, 1 Offset cam or 1 SlamCAM Areas of Application Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Jamb nut > Suitable for interior use
> Installation in wood, laminate, plastic and metal doors and drawers
Locks Washer Operating Modes
4 Screws
Mounting Instruction
> Single Use Mode
2-AA batteries
(Manual Locking only): Allows the user to choose their code at
time of operation
Cylinder length Max. material thickness Recommended for shared lockers or
11 (7/16") 3 (1/8") cabinets in a typical fitness locker
30 (1 3/16") 21 (7/8") room application
45 (1 3/4") 36 (1 7/16") > Assigned Use Mode
(Manual Locking and Self-Locking): Allows for group access
Note to the lock
Other models available upon request.

FC 10.74 www.hafele.com/us
