Locks and Catches
Cabinet and Locker Locks

LockerLock LL 200

> For use with PK programming key card, PK clearing key card,
KT key tag or KB key wristband
> Can be programmed in Stand-Alone mode with PK programming
card and PK clearing key card or with MDU 110/software
> Three free choice of locker versions are available can be
programmed during start-up using the software or MDU 110
> One or several Dialock keys (optional) are allocated to one or
several lockers (optional) for locking and unlocking
> The maintenance tool is required to open the battery compartment
> The type-specific discharge behavior (considerable voltage drop
at the end of the life time) of lithium batteries may cause that a low
battery is indicated at the terminal only for a short period or not at all
> The PK programming key card and PK clearing key card can be
used for emergency opening
> Mifare Classic, Mifare DESfire EV2, Tag-it ISO
Area of application
> Battery-operated, intelligent locker lock for indoor use:
For wood or HPL doors on wardrobes, lockers and cabinets
Version
> Factory settings for right doors, can be adapted to left doors,
batteries theft-proof, magnetic interactions cannot take place,
integrated real-time clock for audit trail of all processes, acoustic
feedback for unlocking and locking, programming/data transfer
with MDU via RFID interface
Functionality
> “Fixed allocation” function, battery monitor: As soon as the battery
32.5 change is indicated, the locker can still be unlocked, but not
(1 1/4") 14 locked again, emergency opening possible with master key
30 22 (7/8") 72 31 (1 1/4") 110 (4 5/16") (9/16") Technical Data
(1 3/16") (2 13/16") Degree of protection: IP20
4 (3/16") Ambient temperature: 0–50 °C
Relative humidity:
10–90% (not condensed)
Ø22 Number of possible Dialock keys: Up to 1000
(Ø7/8") 119 (4 11/16") Number of audit trail entries: 1000
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
(2 1/2") 20 (13/16") Batteries (4 pcs.): AA 1.5 V type E91
64 Battery service life: Approx. 50000 locking and
unlocking processes
LockerLock LL 200

> For door width: With butting overlay door: min. 140 mm (5 1/2"),
with butting inset door: min. 305 mm (12")
(sample measurements, exact dimensions
depend on the hinge)
> For door thickness: 13–19 mm (1/2"–3/4")
> Material: Plastic
10
Finish Item No.
anthracite 231.91.000

Locks

www.hafele.com/us FC 10.79
