Locks and Catches
Cabinet Locks

EFL50/EFL51

→ Locking Component with Push-to-Open Function
44
(1 3/4") > For EFL50
22 > 3-dimensional adjustment with an elegant design
(7/8") > 90° installation facility, for use on both hinged doors and drawers
> The integrated ejector (push-to-open function) with spring force of
5.4 N opens the door automatically as soon it is unlocked; hinges
with a hold-closed function are not suitable for this combination
(1 7/8") > The locking bolt is floating, which can compensate for tolerances
48 12 of +/- 3 mm (1/8")
(1/2")
> The integrated predetermined breaking point of 35 kg (77 lbs.)
protects furniture in the event of forced opening
> Not suitable for constructions with soft and self-closing mechanisms
> Material: Plastic
Finish Item No.
black 231.07.411

→ Locking Component

20 7.9
(13/16") (5/16") > For EFL50/EFL51
> The striking plate has a predetermined breaking point which
breaks at about 35 kg (77 lbs.)
> The locking bolt is floating, which can compensate for tolerances
44 (1 3/4") 60 (2 3/8") of +/- 3 mm
> Suitable for constructions with soft and self-closing mechanisms
> Material: Plastic
5.3 Finish Item No.
(1/4")
black 231.07.410
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
→ Glass Door Set

48 5
(1 7/8") (3/16") > For EFL50/EFL51
> For hinged doors with up to 45 kg (99 lbs.) of pulling force and
sliding doors with up to 25 kg (55 lbs.) of pushing force
> Material: Plastic
61.5 (2 7/16")
Ø4 Finish Item No.
(3/16")
black 231.07.412
Supplied With
Support plate with bonding surface
4 Screws
Black adhesive foil for opposite side 10
→ KT Key Tag, Mifare Classic

Technical Data
Operating temperature: –35 °C – +50 °C (-95° F – +122° F) Locks
Data storage: >10 years
> For EFL50/EFL51
> 4 independent locking authorizations per key tag possible
> Reader range: up to 12 mm (1/2") thick material
> Water resistant
> Material: Plastic

Color Item No.
black 917.64.093
blue 917.64.098
red 917.64.099

www.hafele.com/us FC 10.83
2/23
