Hinges and Stays
Premium Aluminum Frame Doors

Custom Order Doors

How to order:
1. Select frame profile and glass
2. Hinge type and overlay
3. Provide details and dimensions on hinge sizes and drilling
locations
> Hinged doors: Hinge attachment through machined cutouts
> Material: Aluminum

→ Profile → Profile

23 19
(15/16") Front (3/4")
Front
21.5 20.5
(13/16") (13/16")

> 21.5 × 23 mm (13/16" × 15/16")
> 20.5 × 19 mm (13/16" × 3/4")
Finish Item No.
anodized, matt 563.55.931 Finish Item No.
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
brushed stainless steel 563.55.031 anodized, matt 563.55.911
polished aluminum 563.55.531
white 563.55.731 → Profile
bronze 563.55.131
black 563.55.331
9
→ Profile
54 (2 1/8")

(1 3/4")
45
Front
20.5
Front (13/16") Hinges and Stays
> 20.5 × 54 mm (13/16" × 2 1/8")
22.3
(7/8")
Finish Item No.
> 22.3 × 45 mm (7/8" × 1 3/4") anodized, matt 563.55.322
brushed stainless steel 563.55.022
white 563.55.722
Finish Item No. bronze 563.55.122
anodized, matt 563.56.931 black 563.55.422
brushed stainless steel 563.56.031
white 563.56.731
bronze 563.56.131
black 563.56.331
