Hinges and Stays
Decorative Butt Hinges
ELITE
Häfele’s ELITE Decorative Butt Hinge program provides a complete
assortment of hinge choices to complement your decorative hardware.
> Solid brass hinges with decorative finials
> Beautiful finishes designed to complement your handle or knob
> For inset face frame doors
> Mortised on cabinet and/or door side
> 2-way adjustable
→ Mortised Hinges
Ø4.5 2 > Material: Brass
(3/16") (1/16")
1.5
(1/16")
Finish Minaret finial Ball finial Button finial
40.5 (1 5/8") antique brass 354.17.100 354.17.120 354.17.140
Ball
Minaret oil-rubbed bronze 354.17.110 Button 354.17.150
354.17.130
polished chrome 354.17.200 354.17.210 354.17.220
black 354.17.300 354.17.310 354.17.320
Ø4.4 satin chrome 354.17.400 354.17.410 354.17.420
70 33 (3/16") 62 brushed brass 354.17.500 354.17.510 354.17.520
53
(2 3/4") (1 5/16") (2 7/16") brushed nickel (2 1/8") 354.17.610 354.17.620
354.17.600
50 polished nickel 354.17.700 354.17.710 354.17.720
Ø4.5 2 (1 15/16")
(3/16") (1/16") polished brass 354.17.800 354.17.810 354.17.820
1.5
(1/16") pewter 354.17.900 354.17.910 354.17.920
Note
40.5 (1 5/8")
Ball Order #6 x 5/8" screws separately.
Minaret Button
Ø4.4
70 33 (3/16") 62 53
(2 3/4") (1 5/16") (2 7/16") (2 1/8")
50
(1 15/16")
9
→ Flat Head Countersunk Wood Screws > Deep thread design provides maximum holding power in a variety
Hinges and Stays Length > With extra-deep Phillips Recess to help minimize bit slippage Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
of different woods and man-made materials
> Material: Steel, plated
Item No.
Finish
Length (inches)
#6 x 5/8"
010.77.146
antique brass
oil-rubbed bronze
polished chrome
#6 x 5/8"
010.77.246
#6 x 5/8"
010.77.346
black #6 x 5/8" 010.77.546
satin chrome #6 x 5/8" 010.77.446
satin nickel #6 x 5/8" 010.77.646
polished brass #6 x 5/8" 010.77.846
pewter #6 x 5/8" 010.77.946
polished nickel #6 x 5/8" 010.77.606
Supplied With
1000 pcs.
