Hinges and Stays
Concealed Hinges

Blind Corner Hinge

> Door thickness: 16–20 mm (5/8"–13/16")
> Tab: 4–5 mm (5/32"–3/16")

→ Blind Corner Hinge → Pie-cut Corner Hinge

9.5 9.5 22
Tab 4/5 mm
Tab

45 35
45 35
35
11.3 deep
Flat Head 16
Frame-mounting hinge #6 (5/8")
depth 11.5 37 Opening angle:
(1 7/16") Ø35
Opening angle: 71 (1 3/8")
(2 13/16")
Door Door closed Door open 11.5
(7/16")
min. 60
19-20 16
Door (5/8")
16 18
2.5 Alignment of the door corners can be made using the
center adjustment screw in the arm. 20 22
The maximum space required to accommodate the 24 26
Gap
Ø35 hinge is 71 mm (2 13/16") with 16 mm (5/8") thick
doors. With thicker doors the amount of space required
is reduced.
> Self-close or soft close with oil damper in arm
> Screw mounted
> Inset mounting min. 2
> Material: Steel; Finish: nickel-plated (1/16")

Closing Item No.
Self-close 315.05.540
9 Soft close 315.01.740
Note
Mounting plates, see below and next page
→ Mounting Plate
Hinges and Stays > Screw mounted with wood screws > Cup Ø: 35 mm (1 3/8"); Depth: 11.3 mm (7/16") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

> Material: Steel

> Opening angle of first door 60º
Height
Item No.
> Self-close
315.98.650
0
> Tab: 4–5 mm (5/32"–3/16")
→ Mounting Plate
Item No.
314.52.440
> Screw mounted with wood screws
> Material: Steel
Height Item No.
0 314.60.001

Flat head screws pages 12.7-12.8, 12.10, 12.13
