Hinges and Stays
Drilling Hardware

Grass Hinge Machines

→ Grass Pro I > Drilling and insertion machine for 45 mm (1 3/4") boring pattern
> Bore depth automatically adjusts to material thickness
> Functional design; Easy, fast and efficient operation
> Easy maintenance

→ Drill Bit Kit

Model Item No.
00213-01 001.97.510
Supplied With
2 8 mm LH bits
1 35 mm RH bit
> Pneumatic drilling/insertion machine

Description Model Item No.
220V single phase 94559-01 001.97.077
220V three phase 94560-01 001.97.078
110V 94561-01 001.97.079
Supplied With
3 Spindle drilling head with quick-change chucks
Combined stop and ruler 600 mm (23 5/8") long
Wood supporting table 600 x 400 mm (23 5/8" x 15 3/4")
Insertion die arm to hold the insertion die
Hex keys, open-jaw wrenches, 10, 13 and 17 mm (3/8", 1/2", 11/16")
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Side stop left and right
Operating manual

Accessories, optional

→ Drill Bit → Universal Die for Tiomos Hinges
9
> Material: Carbide

Description Item No.
8 x 57 LH 001.06.870
8 x 57 RH 001.08.013 > 110º/120º/160º

→ Short Fence Stop Model Item No. Hinges and Stays
80039 348.40.161
Item No.
001.97.027 → TEC Insertion Die

→ Extension Fence

> 400–1650 mm (15 3/4"–64 8/32")

Item No. Model Item No.
001.97.120 92617 348.91.000
