Drawer Slides
Pull-Out Cabinet Slides

Partial Extension

> Weight capacity: 170 kg (374 lbs.)
> 3 mm (+2/-1) height adjustment with adjusting screw, permitting
alignment of the front panel
> 8 ball bearing mounted plastic covered steel rollers
> 2 friction bearing mounted steel rollers
> 1 friction bearing mounted cylinder steel roller
> Rubber buffers on the rails and runner ensure silent action
> Return guide and retainer provide for the accurate closure of the
cabinet pull-out safety stop
> Material: Steel; Color: gray RAL 7035

98
(3 7/8")
32 32
(1 1/4") (1 1/4")

40 (1 9/16")

→ HAWA Forte 170/340 Top/Bottom Mounted

max. 2200 (86 5/8")

8 Installed length Extension length Item No.
*385 (15 3/16") 380 (14 15/16") 421.48.381
120
435 (17 1/8") 430 (16 15/16") 421.48.431 (1 7/8") (1 7/8")
(4 3/4")
421.48.481
485 (19 1/16")
480 (18 7/8")
48
48
Drawer Slides 585 (23") 580 (22 13/16") 421.48.581 87 (3 7/16")
535 (21 1/16")
530 (20 7/8")
421.48.531
421.48.631
635 (25")
630 (24 13/16")
685 (27")
421.48.681
680 (26 3/4")
780 (30 11/16")
421.48.781
785 (30 15/16")
42 42
885 (34 13/16")
985 (38 3/4") 880 (34 5/8") 421.48.881 (1 5/8") (1 5/8")
980 (38 9/16")
421.48.981
1085 (42 3/4") 1080 (42 1/2") 421.48.991 110
(4 5/16")
Supplied With max. 600
Top runner, Mounting instructions (23 5/8") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Note
Damping is not possible on the shortest length.
max.
340 kg
84 44 84
(3 5/16") (1 3/4") (3 5/16")
110 18 110
(4 5/16") (11/16") (4 5/16")
max. 800
(31 1/2")
