Drawer Slides
Concealed Undermount

Grass Elite Plus Accessories

> Choose from required front locking devices

→ 2D Adjustable Front Locking Device, required

> +/- 1.5 mm (1/16") side
→ 1D Front Locking Device, required > +/- 2.5 mm (1/8") height
> Material: Plastic

Version Handing Pairs Bulk
Without flange With flange Without flange right 433.30.004
Without flange left 433.30.008 433.30.005
With flange right 433.30.011 433.30.009
With flange left 433.30.010
Bulk Supplied With
Flat Head
#6 200 pairs
> Material: Plastic → Rear Mounting Bracket, optional
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
8
Rear Bracket Position
Version Handing Pairs Bulk
17.5
Without flange right 433.30.000 (11/16")
Without flange left 433.30.006 433.30.001
With flange right 433.30.007 433.30.002 21
With flange left 433.30.003 (13/16")
Bulk Supplied With
200 pairs Drawer Slides
32
(1 1/4") Frame
→ Drilling Template stile
16
(5/8")
Frame
rail 9
(11/32")
For face frame
applications only.
Use minimum of
3 screws per bracket,
#6 x 1/2" truss head screws
> For use with a standard 6 mm (1/4") drill bit and stop collar > For use in face frame applications
> Material: Steel

Item No. Finish Item No.
433.25.996 zinc-plated 433.19.051

Flat head screws pages 12.7-12.8, 12.10, 12.13
