Page 60 - Furniture Cabinetry Hardware-FloorKitchenResource.com
P. 60
Kitchen Organization
Waste Bins
Wood Frame Bottom Mount
3
> Integrated Grass Elite 36 kg (80 lb.) capacity soft close slides
> Dovetailed construction
> Easy mounting to the cabinet floor with supplied screws
> Supplied with adjustable door mounting brackets
Kitchen Organization
> For replacement bins and lids, see page 3.29
> Material: Prefinished Baltic Birch Plywood Sides; Solid Birch Top
Bin: Plastic; Color: gray
→ Single Waste Bin → Double Waste Bins
Height Height
571 571
(22 1/2") (22 1/2")
292 366
(11 1/2") (14 7/16")
> W × D: 292 x 572 mm (11 1/2" x 22 1/2") > W × D: 367 x 572 mm (14 7/16" x 22 1/2") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Capacity Height Item No. Capacity Height Item No.
36 qts. 495 (19 1/2") 503.88.852 2 x 36 qts. (72 qts.) 495 (19 1/2") 503.88.862
52 qts. 610 (24") 503.88.853 2 x 52 qts. (104 qts.) 610 (24") 503.88.863
Supplied With Supplied With
Mounting screws for pull-out Mounting screws for pull-out
1 Bin 2 Bins
Mounting instructions Mounting instructions
FC 3.46 www.hafele.com/us
