Sliding and Roller Shutter Systems
Sliding Wood Door Fittings

Häfele Slido F-Line21 12C

> Door weight: max. 12 kg (26 lbs.)
> Door height: max. 1,200 mm (3' 11 1/4")
> Door width: max. 1,000 mm (3' 3 3/8")
> Door thickness: 16–19 mm (5/8"–3/4")
> Height adjustment: +/‑ 1.5 mm (1/16") on running gear using
adjusting wheel
> Mounts quickly and easily
> Space saving compared to hinged doors
> Optional soft closing mechanism

16 (5/8") 10 (13/32") 16 (5/8") 10 (13/32") 16 (5/8") 10 (13/32") 16 (5/8") 10 (13/32")

13 (1/2")
19
(3/4")
5.5
7 Drilling pattern Door overlap 20 (7/32")

*50 (25/32") 5 5
(1 31/32") 64 (3/16") (3/16")
(2 17/32")
Sliding and Roller Shutter Systems
12
(15/32")
Ø35 AB AB
(1 3/8")
12
(15/32") * = + 43 (1 11/16") when using
service port
11 7 (10) 7 (10)
(7/16") (9/32") (13/32") (9/32") (13/32")
19 (16) (3/4") (5/8") 19 (16) (3/4") (5/8") 19 (16) (3/4") (5/8") 19 (16) (3/4") (5/8")

9.5 9.5 9.5
6
6
(3/8") (1/4") (3/8") (1/4") (3/8")
6
(1/4")
4.5 (3/16") 4.5 (3/16")
12 (1/2") 12 (1/2")
*≥325 (12 13/16")
Ø8 Ø8
(5/16") 26 (5/16") 26
(1 1/32") 14.5 (1 1/32") 14.5
*≥325 (12 13/16") (9/16") (9/16") Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Groove mounted track Screw mounted track
≥225 (8 7/8")
A = internal cabinet height A = internal cabinet height
Minimum door width with one soft closing mechanism. B = internal cabinet height B = internal cabinet height
minus 23.5 mm (15/16")
minus 10 mm (13/32")
≥515 (20 1/4")
*Add 43 mm (1 11/16") when using service port.
≥225 (8 7/8")
Door panel installation
≥515 (20 1/4") click click
≥415 (16 5/16")

2 4
≥415 (16 5/16")

Minimum door width with two soft closing mechanisms.
1 3
