Laundry Hampers

Laundry Hampers

→ Flap Stay Hamper Kit

> Material: Steel

Finish Item No. 4
nickel-plated 547.42.993
black 547.42.994
Supplied With
Smove shock absorber 4 Varianta screws
Smove adapter bracket 6 Countersunk wood screws
2 Duo flap stays 2 Pan head screws
2 37 mm Cabinet brackets 4 mm hex key
2 Wood door brackets

→ FLAP-EX Flap Hinge

> Particularly suitable for installing in cabinets with a laundry hamper Home and Closet Organization
> The door is opened approximately 27°
> When the door is closed, the flap is pushed back into the cabinet
15
(9/16")
The door is 12 Side panel and secured by the Mini Latch, required
opened by pushing 5 (1/2") 28 > For cabinet sizes from 820 mm (32 5/16") high, 400 mm (15 3/4")
against the door (3/16") (1 1/8") wide inside cabinet depth of at least 270 mm (10 5/8")
101
32
panel. The pressure (3 31/32") (1 1/4") > Material: Steel; Bearing: Plastic
triggers the release 254
spring in the fitting Front flap (10")
and the door opens Finish Item No.
automatically. nickel-plated 365.52.708
To close the door,
slightly press Flat Head 32 (1 1/4") Supplied With
against the #6 Angle bracket, Rod and plastic sleeve, 2 Washers, 2 Coil Springs, Bearing
door panel. 20.5 Note
(7/8")
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
23.3 Completely assembled. For installation of the front flap, 2 cup hinges
(15/16") and a Mini Latch are required. The hinge with the coil springs is
designed to support a particle board front with maximum dimensions
590 mm (23 1/4") high, 400 mm (15 3/4") wide and 19 mm (3/4") thick
and a maximum weight when full of 5 kg (11 lbs).
Washer Screw mount bearing Washer Mounting Instructions
Coil spring
Coil spring
Angle 126 mm long 90 mm long Screw the angle bracket to front panel and screw mount bearing to
cabinet side panel; see mounting drawing on the right. Push round
bracket
140 (5 33/64") rod into the screw-on bearing between the two coil springs.
VARIANTA
5
Floor
→ Mini Latch

13 11 11
(1/2") (7/16") (7/16") > Screw mounted
34 5 > With strike
(1 5/16") (3/16") > Material: Catch: Steel; Strike: Plastic; Color: white
(1 1/16") 32 (1 1/4") (1/8")
3
27 Finish Item No.
Strike nickel-plated 245.54.701
Pan Head 3
#6 (1/8") 19 (3/4")
14 11
(9/16") (7/16")
Catch

Varianta screws page 12.16
Flat head screws pages 12.7–12.8, 12.10, 12.13
Pan head screws pages 12.9-12.10

www.hafele.com/us FC 4.119
