Home and Closet Organization
Wardrobe Fittings

Laundry Hampers

> The door is opened under spring tension approximately 27º
by simply applying pressure directly to the door
> The release function can be activated with light pressure on the door
> Door opens automatically
> To close door, light pressure against door is required
> Material: Steel; Finish: chrome-plated
4 Note
Flap-ex flap hinge and mini latch are required for door operation,
see page 4.119. Door
Home and Closet Organization → Laundry Hamper Side Catch Strike
Mounting
diagram

panel

> With lowered handles, hangs on mounting rail
> For cabinet width: 300 mm (11 3/4")
> Capacity: 23.5 liters (6 gal.)
> W x D: 238 x 259 mm (9 3/8" x 10 3/16")
> Height: rear 365 mm (14 3/8"); front 420 mm (16 1/2")

Item No.
540.02.112

> With lowered handles, hangs on mounting rail
> For cabinet width: 450 mm (17 3/4")
> Capacity: 39 liters (10 gal.)
> W x D: 388 x 259 mm (15 1/4" x 10 3/16")
> Height: rear 365 mm (14 3/8"); front 420 mm (16 1/2")

Item No.
540.02.121

→ Mounting Bracket

> For laundry hamper above
> Screw mounted Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
> Width: 214 mm (8 7/16")
> Spacing between holes: 160 mm (6 19/64")

Item No.
Pan Head
#8 540.02.194

Pan head screws pages 12.9-12.10
