Hinges and Stays
Classic Aluminum Frame Doors
Cut-To-Size Doors
> No drilling required
> Pre-attached slotted screws secure hinge to aluminum frame
→ Corner Connector
> With 2 clamping screws for 23 mm (15/16") wide aluminum frame
profiles to connect miters
> Material: Zinc Alloy
Finish Item No.
nickel-plated 563.25.910
Note
4 pcs. required per frame.
→ Corner Connector
> With 4 clamping screws for 38 mm (1 1/2") wide aluminum frame
profiles to connect miters
> Material: Zinc Alloy
Finish Item No.
nickel-plated 563.25.912
Note
4 pcs. required per frame.
→ Lid Stay Adapter Bracket
> Insert into frame before mounting the glass panels
> Material: Zinc
32 Finish Item No.
(1 1/4”)
nickel-plated 563.25.960
Supplied With
9 Note 2 Mounting screws
Can be used
with Duo lid stay
and 373.66.693
as the door
bracket,
Hinges and Stays → Plastic Gasket Profile > For glass or panel inserts Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
see page 9.140
> For glass panel thickness of 4 mm (5/32")
> Insert into frame before mounting the glass panels
> Length: 2.5 m (8' 2 7/16")
> Material: Plastic, transparent
Item No.
563.25.924
