Hinges and Stays
Lid and Flap Stays

Salice Pacta

> With automatic closing spring or Push version
> Integrated soft opening mechanism in opening direction
> Without additional hinge connection
> Flap and base panel are on one level in open position
> Clips onto cabinet
> Drilling depth: 13 mm (1/2")
> Adjustment facility: Side adjustment from -1.5 – +1.5 mm
(-1/16" – +1/16")
Height adjustment from -1.5 – +1.5 mm
(-1/16" – +1/16")
Depth adjustment from -0.5 – +2.8 mm
(-1/64" – +1/8")
> Overlay: 17 mm (11/16") (fixed)
> Door height: 280–400 mm (11 1/32"–15 3/4")
> Door width: <900 mm (35 7/16")
> Material: Zinc Alloy; Finish: nickel-plated
Note Cover caps, see page 9.164

→ Flap Stay

With Push, without
automatic automatic
Model closing closing
spring spring
W 365.13.700 365.13.710
I 365.13.701 365.13.711
S 365.13.702 365.13.712
119 T Base panel Supplied With 2 Hinges, 2 Mounting plates, 2 Soft opening
(4 11/16")
Flap in closed position mechanisms, Screws
Flap in open position
Note Order Push magnetic catch separately
H=2 (1/16") 90º Ø35
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
10.5+D
19 D E (1 3/8") (7/16") 19+D (3/4")
(3/4")
17 (11/16")
Ø5x13
Weight capacity table E F 34 32 41 13
Door weight in lbs. (1 5/16") (1 1/4") (1 5/8") 22 (7/8") 29 (1 1/8") (1/2")
Door height 9
Model W Model I Model S Side panel Safety lock screw D = overlay
280 (11 1/32") 6.2-9.5 9.5-14.5 14.7-21
300 (11 13/16") 5.7-9 9-13.6 13.6-9.7 Door 16 17 18 19 20 21 22 23 24 25 26 27 28
320 (12 5/8") 5.5-8.6 8.4-12.8 12.8-18.3 thickness
340 (13 3/8") 5.1-8.2 8.2-11.9 11.9-17.4 (5/8") (11/16") (23/32") (3/4") (25/32") (27/32") (7/8") (29/32") (15/16") (1") (1 1/32") (1 1/16") (1 3/32")
360 (14 3/16") 4.8-7.7 7.9-11 11-16.3
380 (14 15/16") 4.6-7.3 7.7-10.3 10.3-15.4 Distance to 1.3 2.1 3.0 3.9 4.8 5.7 6.6 7.5 8.5 9.4 10.4 11.3 12.3
400 (15 3/4") 4.4-5.3 7.3-9.9 9.9-14.5 cup E (fixed)
4.5 mm (3/64") (15/64") (1/8") (5/32") (3/16") (7/32") (17/64") (19/64") (21/64") (3/8") (13/32") (7/16") (31/64") Hinges and Stays
(11/64")
Minimum gap F

→ Center Hinge

Finish Item No.
gray 372.76.600
white 372.76.601
black 372.76.602

www.hafele.com/us FC 9.163
