Sliding and Roller Shutter Systems
Sliding Wood Door Fittings

→ HAWA Clipo 36 HM IF Set

Version Supplied with Item No.
2 running gears with housings
For 1 door With clip-in door stopper 2 door stoppers 405.02.408
1 floor guide
Supplied With
1 set
Note
Please order running and guide tracks separately. Soft closing mechanism on one side is possible from pitch length of min. 260 mm (10 1/4"),
both sides from 460 mm (18 1/8"). Please order soft closing mechanism set for soft closing on both sides separately.

→ Tracks and Accessories

Description Material Finish Length/Door weight Item No.
Upper track, pre-drilled, 2.5 m (8’ 2 7/16”) 405.00.622
for screw mounting Aluminum anodized silver
3.5 m (11’ 5 13/16”) 405.00.623
2.5 m (8’ 2 7/16") 406.73.803
Lower guide channel Plastic gray
3.5 m (11’ 5 13/16") 406.73.804
Soft closing mechanism, optional
for screw mounting to housing up to 15 kg (33 lbs.) 405.10.073
Plastic –
One set includes two mechanisms
Two sets are required for dual soft 15.4–26 kg (34–57 lbs.) 405.10.074
closing of two doors 7
Service port for upper track (to access Plastic gray – 405.00.072
running gear after installation)

Soft stop, for screw mounting
to the back of the front door – – – 405.93.012
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Optional for a two door application Sliding and Roller Shutter Systems

Planofit door straightening page 7.91
