Office Organization
Power and Charging

Docking Drawer Style Drawer Flush 20 Amp Series

Ideally suited narrow and shallow drawers, the 20 amp Style Drawer
Flush powering outlets are designed to fit into narrow vanity
drawers. Style Drawer Flush features an Interlock Thermostat that
de-energizes the outlet if the surrounding temperature
exceeds 120° F.
Need to Install Style Drawer Flush into a drawer less than Outlet Features
267 mm (10.5") wide? Try our Narrow Drawer Installation > Keep your devices plugged in, ready to use and neatly stowed
Tip: > Outlets can be mounted horizontally, vertically, left or right
> Works with any side mount, undermount and soft close slides
> ETL Listed to UL962a
Mounting Details
minimum > Minimum space behind drawer box: 127 mm (5")
5 drawer box > Minimum interior drawer box height: 102 mm (4")
width (OD)
Electrical Specifications
> Hardwired connection
minimum > Max rated current: AC: 20 amps
Office Organization for channel Safety Features
drawer box
@ 120 VAC
height
> Interlock Thermostat - De-energizes outlet when the surrounding
of space
needed
temperature exceeds 120°F
height
→ Style Drawer Flush 18

> With 2 x AC GFCI Outlets
> For ≤ 457 mm (18") cabinet depths, min. drawer box with (OD)
≥ 268 mm (10.5")
> Material: Metal with Plastic and Electrical Components

Finish Model Item No.
black 0290-00050B 822.53.027
white 0290-00050W 822.53.028
stainless steel 0290-00050S 822.53.053

→ Style Drawer Flush 21

> With 2 x AC GFCI Outlets
> For ≤ 533 mm (21") cabinet depths, min. drawer box with (OD)
≥ 305 mm (12")
> Material: Metal with Plastic and Electrical Components

Finish Model Item No.
black 0290-00032B 822.53.019
white 0290-00032W 822.53.020 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
stainless steel 0290-00032S 822.53.072

→ Style Drawer Flush 24

> With 2 x AC GFCI Outlets
> For ≤ 610 mm (24") cabinet depths, min. drawer box with (OD)
≥ 343 mm (13.5")
> Material: Metal with Plastic and Electrical Components

Finish Model Item No.
black 0290-00033B 822.53.017
white 0290-00033W 822.53.018
stainless steel 0290-00033S 822.53.073
