Office Organization
Power and Charging
Docking Drawer Blade Duo and Blade - 20 Amp Series
The Docking Drawer Blade and Blade Duo in-drawer outlets are
rated for any charging or powering applications and are designed
to fit into almost every cabinet. The 20 amp Docking Drawer Blade
Duo and Blade are an all-in-one series which can charge
AND power any type of device in even more compact spaces.
All Docking Drawer Blade and Blade Duo feature an Interlock
Thermostat that de-energizes the outlet if the surrounding
temperature exceeds 120° F.
Outlet Features
> Keep your devices plugged in, ready to use and neatly
stowed away
> Outlets can be mounted horizontally, vertically, left or right
5 > Works with any type of side mount, undermount
and soft closing slides
> ETL Listed to UL962a
Cabinet Specifications
> Fits shallow drawers:
Office Organization > Fits tall drawers:
Minimum drawer box width (OD): 380 mm (15")
Minimum interior drawer box height: 76 mm (3")
Minimum drawer box width (OD): 330 mm (13")
Minimum interior drawer box height: 101 mm (4")
> Fits narrow drawers:
Minimum drawer box width (OD): 228 mm (9")
Minimum interior drawer box height: 101 mm (4")
> Fits vertical drawers:
Minimum drawer box width (OD): 203 mm (8")
Minimum interior drawer box height: 330 mm (13")
Electrical Specifications
> 3' NEMA 5-20P power cord plugs into
a NEMA 5-20R receptacle
> Max. current: AC: 16 amps @ 120 VAC
USB-A: 3.6 amps @ 5VDC
Safety Features
> Interlock Thermostat - De-energizes outlet when the surrounding
temperature exceeds 120°F
Requires a 20 amp wall receptacle with T-shaped
prongs for the NEMA 5-20P
Features 3' long heavy-duty 12 AWG power cord
Features 3
with NEMA 5-20P plug and 20 amp receptacle
with NEMA 5-20P plug and 20 amp receptacle Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
FC 5.7A www.hafele.com/us
2/22
