Kitchen Organization
Corner Solutions

Lazy Susans
3
> Tested to 100,000 cycles
> Made in USA
> Telescopic post adjusts without tools
> Anti-slip ribs for sliding resistance
> Shelves are safely secured with a steel pin through the post
> Rigid double wall shelf construction guarantees a heavy weight
carrying capacity
> Top and bottom shelf height adjustment
> Single bump stop
> Inside shelf rim height: 28 mm (1 1/8")
> For hinged door applications Kitchen Organization
> Shelves rotate independently
> Weight capacity per shelf: 457 mm (18") - 12.7 kg (28 lbs.)
610 mm (24") - 22.6 kg (50 lbs.)
710 mm (28") - 31.7 kg (70 lbs.)
813 mm (32") - 43 kg (95 lbs.)
> Material: Polypropylene; Color: white; Post: Steel; Finish: chrome

→ Full Round Two Shelf Set

> Post fits inside cabinet heights: 660–813 mm (26"–32")

Ø Item No.
457 (18") 542.96.701
610 (24") 542.96.702
711 (28") 542.96.704
813 (32") 542.96.705
Supplied With
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
2 Shelves
Post
For 45º hinged corner door
C
A
D
B
C A B C D
610 (24") 432 (17") 305 (12") 457 (18") 460 (18 1/8") 244 (9 5/8")
686 (27") 432 (17") 381 (15") 457 (18") 460 (18 1/8") 244 313 (9 5/8")
D A
838 (33") 330 (13") 610 (24") 610 (24") 600 (23 5/8") 313 (12 5/16")
914 (36") 432 (17") 610 (24") 711 (28") 721 (28 3/8") 378 (14 7/8")
991 (39") 533 (21") 610 (24") 711 (28") 721 (28 3/8") 378 (14 7/8")
1067 (42") 648 (25 1/2") 610 (24") 813 (32") 821 (32 5/16") 424 (16 11/16")
B
